Главная Каталог продукции Toolunited 17 303-06 - Ball-nosed end mill DSK.MD.030.383 MD10

DSK.MD.030.383 MD10

Артикул: DSKMD030383MD10

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

0.15 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

HORN - Paul Horn

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

0.3 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

6/27/2017

DIN

ZYL00300105

DN Neck diameter

1.6 mm

FamilyProducts

Schaftfräser DSK.MD bestückt mit Monokristallinem Diamant als Mikrofräser zum Glanzfräsen, 1-schneidig.

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

GRDMFG Grade manufacturers designation

MD10

HAND Cutting direction

R - Right

ID Technical product number

DSKMD030383MD10

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LN Neck length

5 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0030

LOC-03 DCONMS Diameter

3 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$05

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00300105

Name Identifying order number

DSK.MD.030.383 MD10

OAL Overall length

38 mm

PRFRAD Profile radius 1

0.15 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

FEC - Square shoulder milling,FNU - Groove milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
