Главная Каталог продукции Toolunited 17 303-01 - Non-centre cutting end mill SP4081.125P1S.3Z6

SP4081.125P1S.3Z6

SP4081.125P1S.3Z6 SP4081.125P1S.3Z6 SP4081.125P1S.3Z6 SP4081.125P1S.3Z6

SP4081.125P1S.3Z6

Seco
Артикул: 17011056
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
50.8 mm
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
28.575 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2018
DIN
ZYL10001025
F71 Number of corner designs
1
FamilyProducts
SP4081.125P1S.3Z6
FHA Flute helix angle
30 Degree
FHH Flute helix hand
R - Hand of helix right
GAMF Rake angle radial
30 Degree
GAMP Rake angle axial
10 Degree
HAND Cutting direction
R - Right
ID Technical product number
17011056
Interface codes
J6 / J61
ISO
ZYL10S1000h$05
ISYC Subclass
303-01 - Non-centre cutting end mill
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
1000
LOC-03 DCONMS Diameter
25.4 mm
LOC-03 ISO
ZYL10S1000h$05
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL10001025
LS Shank length
57.94 mm
Name Identifying order number
SP4081.125P1S.3Z6
NameAnsi Identifying order number inch alternative
SP408-1.125-P1-S.3-Z6
OAL Overall length
114.3 mm
Working process
No working processes available
WT Weight of item
0.435 kg
ZEFP Peripheral effective cutting edge count
6
