Главная Каталог продукции Toolunited 17 303-01 - Non-centre cutting end mill SHM511-0800BZ02R-F0010HA-PU611

SHM511-0800BZ02R-F0010HA-PU611

Артикул: 30696689

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

10 mm

BMC Body material code

D - Solid steel with soldered hard-alloy inserts (BN or DP)

CHW Corner chamfer width

0.1 mm

CNSC Coolant entry style code

2 - With Coolant entry, radial

COATN Coating / Покрытие

PKD-bestückt

COMPC Company code

MP - Mapal

CXSC Coolant exit style code

2 - With Coolant exit, radial

DC Cutting diameter

8 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/10/2017

DIN

ZYL00800115

F71 Number of corner designs

FamilyProducts

OptiMill®-Diamond-Typ 51 Überlange Ausführung mit Hals, mit Innenkühlung

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

GAMF Rake angle radial

0 Degree

GAMP Rake angle axial

0 Degree

GRDMFG Grade manufacturers designation

PU611

HAND Cutting direction

R - Right

ID Technical product number

30696689

Interface codes

J6 /

ISYC Subclass

303-01 - Non-centre cutting end mill

KCH Corner chamfer angle

45 Degree

LF Functional length

80 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0080

LOC-03 DCONMS Diameter

8 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00800115

LPR Protruding length

20 mm

Name Identifying order number

SHM511-0800BZ02R-F0010HA-PU611

OAL Overall length

80 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
