Главная Каталог продукции Toolunited 17 303-09 - Thread end mill NTM120NR.10X32UN.187 ALCRN

NTM120NR.10X32UN.187 ALCRN

NTM120NR.10X32UN.187 ALCRN NTM120NR.10X32UN.187 ALCRN NTM120NR.10X32UN.187 ALCRN NTM120NR.10X32UN.187 ALCRN

NTM120NR.10X32UN.187 ALCRN

Seco
Артикул: 17000430
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
7.95 mm
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
3.404 mm
Delivery state valid from
12/1/2023
DIN
ZYL01870135
FamilyProducts
NTM120NR.10X32UN.187 ALCRN
GRDMFG Grade manufacturers designation
ALCRN
HAND Cutting direction
R - Right
ID Technical product number
17000430
Interface codes
J6 /
ISYC Subclass
303-09 - Thread end mill
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
3 Inch with coolant
LOC-03 CZCMS Connection size code
0187
LOC-03 DCONMS Diameter
4.762 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01870135
LPR Protruding length
25 mm
LS Shank length
41.148 mm
MILTTY Mill tool type ISO
T - Thread cutter
Name Identifying order number
NTM120NR.10X32UN.187 ALCRN
NameAnsi Identifying order number inch alternative
NTM120-NR.10X32UN-.187
OAL Overall length
50.8 mm
RPMX Rotational speed maximum
10000 1/min
TDFR Thread diameter nominal fraction
10 in
TPI Threads per inch
32 1/in
Working process
No working processes available
WT Weight of item
0.009 kg
ZEFP Peripheral effective cutting edge count
3
