Главная Каталог продукции Toolunited 17 303-02 - Centre cutting end mill STR440.250D2R020.0Z4 ALCRN

STR440.250D2R020.0Z4 ALCRN

STR440.250D2R020.0Z4 ALCRN STR440.250D2R020.0Z4 ALCRN STR440.250D2R020.0Z4 ALCRN STR440.250D2R020.0Z4 ALCRN

STR440.250D2R020.0Z4 ALCRN

Seco
Артикул: 17004128
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
12.7 mm
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
6.35 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
6/7/2017
DIN
ZYL02500125
F71 Number of corner designs
1
FamilyProducts
STR440.250D2R020.0Z4 ALCRN
FHA Flute helix angle
40 Degree
GAMF Rake angle radial
40 Degree
GAMP Rake angle axial
12 Degree
GRDMFG Grade manufacturers designation
ALCRN
HAND Cutting direction
R - Right
ID Technical product number
17004128
Interface codes
J6 /
ISYC Subclass
303-02 - Centre cutting end mill
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
0250
LOC-03 DCONMS Diameter
6.35 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02500125
LS Shank length
36 mm
Name Identifying order number
STR440.250D2R020.0Z4 ALCRN
NameAnsi Identifying order number inch alternative
STR440-0.250-D2-R020.0-Z4 ALCRN
OAL Overall length
63.5 mm
RE Corner radius
0.508 mm
Working process
No working processes available
WT Weight of item
0.1 kg
ZEFF Face effective cutting edge count
4
ZEFP Peripheral effective cutting edge count
4
