Главная Каталог продукции Toolunited 17 303-02 - Centre cutting end mill SFRHEC625S3125 K600

SFRHEC625S3125 K600

SFRHEC625S3125 K600

SFRHEC625S3125 K600

Kennametal
Артикул: 2658447
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
31.75 mm
BMC Body material code
D - Solid steel with soldered hard-alloy inserts (BN or DP)
CHW Corner chamfer width
1.001 mm
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
15.875 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
8/27/2014
DIN
ZYL06251025
F71 Number of corner designs
1
FamilyProducts
SOLID CARBIDE ENDMILL D=0.625 Z=3
FHA Flute helix angle
37 Degree
GRDMFG Grade manufacturers designation
K600
HAND Cutting direction
R - Right
ID Technical product number
2658447
Interface codes
J6 /
ISYC Subclass
303-02 - Centre cutting end mill
KCH Corner chamfer angle
45 Degree
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
0625
LOC-03 DCONMS Diameter
15.875 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL06251025
LS Shank length
49.9364 mm
MILTTY Mill tool type ISO
E - Disc mill - one side cutting
Name Identifying order number
SFRHEC625S3125 K600
OAL Overall length
88.9 mm
Working process
No working processes available
ZEFF Face effective cutting edge count
3
ZEFP Peripheral effective cutting edge count
3
ZNC Cutting edge centre count
1
