Главная Каталог продукции Toolunited 17 303-02 - Centre cutting end mill MM EA.500B31R031-3T08 IC08

MM EA.500B31R031-3T08 IC08

MM EA.500B31R031-3T08 IC08 MM EA.500B31R031-3T08 IC08

MM EA.500B31R031-3T08 IC08

Iscar
Артикул: 5622733
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
8 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
Uncoated
COMPC Company code
IS - Iscar
CRCLMFG Chip removal class mfg
IC08
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
12.7 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
2/2/2018
DIN
SAI00800105
DN Neck diameter
12.4 mm
F71 Number of corner designs
1
FamilyProducts
Interchangeable Solid Carbide Slot Drill Milling Heads for Machining Aluminum
FHA Flute helix angle
45 Degree
FHH Flute helix hand
R - Hand of helix right
GRDMFG Grade manufacturers designation
IC08
HAND Cutting direction
R - Right
ID Technical product number
5622733
Interface codes
J6 / J61
ISO
SAI01F8000$$$$
ISYC Subclass
303-02 - Centre cutting end mill
LF Functional length
16.5 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SAI Screw mounting ISCAR
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0080
LOC-03 DCONMS Diameter
12.4 mm
LOC-03 ISO
SAI01F8000$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SAI00800105
Name Identifying order number
MM EA.500B31R031-3T08 IC08
RE Corner radius
0.8 mm
RMPX Ramping angle maximum
90 Degree
Working process
No working processes available
WT Weight of item
0.02 kg
ZEFF Face effective cutting edge count
3
ZEFP Peripheral effective cutting edge count
3
