Главная Каталог продукции Toolunited 17 303-02 - Centre cutting end mill HDP8902.000D3S.7Z8 TICN

HDP8902.000D3S.7Z8 TICN

HDP8902.000D3S.7Z8 TICN HDP8902.000D3S.7Z8 TICN HDP8902.000D3S.7Z8 TICN HDP8902.000D3S.7Z8 TICN

HDP8902.000D3S.7Z8 TICN

Seco
Артикул: 17012569
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
101.6 mm
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
50.8 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
6/7/2017
F71 Number of corner designs
1
FamilyProducts
HDP8902.000D3S.7Z8 TICN
FHA Flute helix angle
30 Degree
GAMF Rake angle radial
30 Degree
GAMP Rake angle axial
10 Degree
GRDMFG Grade manufacturers designation
TICN
HAND Cutting direction
R - Right
ID Technical product number
17012569
Interface codes
/
ISYC Subclass
303-02 - Centre cutting end mill
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
2000
LOC-03 DCONMS Diameter
50.8 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LS Shank length
82.55 mm
Name Identifying order number
HDP8902.000D3S.7Z8 TICN
NameAnsi Identifying order number inch alternative
HDP890-2.000-D3-S.7-Z8 TICN
OAL Overall length
196.85 mm
Working process
No working processes available
WT Weight of item
2.7 kg
ZEFF Face effective cutting edge count
8
ZEFP Peripheral effective cutting edge count
8
