5586R554HHR30-1200 KMG405

Артикул: 5586R554HHR30-1200 KMG405

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

12 mm

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

AlCrN

COMPC Company code

ZCC - ZCC Cutting Tools

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

12 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1.67 kg

DIN

ZYL01200105

DN Neck diameter

11 mm

F71 Number of corner designs

FamilyProducts

ZCC CT 4-flute ball nose end mills machining high hardness steel (HRC>48)

FHA Flute helix angle

55 Degree

GRDMFG Grade manufacturers designation

KMG405

HAND Cutting direction

R - Right

ID Identifying order number

5586R554HHR30-1200 KMG405

Interface codes

J6 /

ISYC Subclass

303-02 - Centre cutting end mill

LF Functional length

120 mm

LN Neck length

74 mm

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

ZYL cylindrical shank

LOC-03 CCUMS Unit base

0 Metric

LOC-03 CZCMS Size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03 TCDCONCDMS Tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01200105

MILTTY Mill tool type ISO

N - Torus End Mill

OAL Overall length

120 mm

RE Corner radius

3 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

FEC - Square shoulder milling,FFO - Die milling,FPL - Face milling,FZI - Circular milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
