Главная Каталог продукции Toolunited 17 307-07 - Non-centre cutting multiple rows end mill P290 ACK D44-3-53-C4-18

P290 ACK D44-3-53-C4-18

Артикул: 3107187

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

53 mm

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter

44 mm

DCP Data chip provision

0 - Without data chip

DIN

CCS04000295

FamilyProducts

Extended Flute Endmills with CAMFIX Shanks Carrying 18 mm Long Edged Inserts

HAND Cutting direction

R - Right

ID Technical product number

3107187

Interface codes

J6 / J61

ISO

CCS02C0400$$$$

ISYC Subclass

307-07 - Non-centre cutting multiple rows end mill

KAPR Tool cutting edge angle

90 Degree

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

CCS Coromant Capto System SANDVIK

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0400

LOC-03 DCONMS Diameter

40 mm

LOC-03 ISO

CCS02C0400$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

CCS04000295

Name Identifying order number

P290 ACK D44-3-53-C4-18

OAL Overall length

91 mm

RMPX Ramping angle maximum

1.2 Degree

Working process

No working processes available

WT Weight of item

0.93 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
