Главная Каталог продукции Toolunited 17 307-07 - Non-centre cutting multiple rows end mill HUU250R566M631A15F6

HUU250R566M631A15F6

HUU250R566M631A15F6

HUU250R566M631A15F6

Kennametal
Артикул: 5517274
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
143.9164 mm
BD Body diameter
60.7568 mm
BLDA Tool style code Position A
5
BLDB Tool style code Position B
5
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
1
CICT Cutting item count
60
COMPC Company code
KH - Kennametal
DC Cutting diameter
63.5 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
8/27/2014
DIN
FLK11803110
FamilyProducts
Helical Harvi Ultra Cutter in diameter 2
GAMF Rake angle radial
10 Degree
GAMP Rake angle axial
-3 Degree
HAND Cutting direction
1
ID Technical product number
5517274
Interface codes
J6 /
ISYC Subclass
307-07 - Non-centre cutting multiple rows end mill
KAPR Tool cutting edge angle
90 Degree
LOC-02 BI Block index
2
LOC-02 MIID Master insert identification
ADCT2328PD R
LOC-02 MTP Clamping type code 1st step
S Screwed on across the bore, with counter bore
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
AD1545PD3R
LOC-03 CCFMS Connection code form
31
LOC-03 CCTMS Connection code type
FLK Flange mounting KENNAMETAL
LOC-03 CZCMS Connection size code
1180
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FLK11803110
LPR Protruding length
190.5 mm
MILTTY Mill tool type ISO
E - Disc mill - one side cutting
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
HUU250R566M631A15F6
OAL Overall length
190.5 mm
RPMX Rotational speed maximum
6125 1/min
Working process
No working processes available
ZEFF Face effective cutting edge count
5
ZEFP Peripheral effective cutting edge count
5
