Главная Каталог продукции Toolunited 17 307-07 - Non-centre cutting multiple rows end mill H490 ANK D40-49-4-W32-09C

H490 ANK D40-49-4-W32-09C

H490 ANK D40-49-4-W32-09C

H490 ANK D40-49-4-W32-09C

H490 ANK D40-49-4-W32-09C

H490 ANK D40-49-4-W32-09C

Iscar

Артикул: 3105904

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

90 Degree

A1B Cutting edge angle major Pos. B

90 Degree

A2A Clearance angle major Pos. A

0 Degree

A2B Clearance angle major Pos. B

0 Degree

APMX Depth of cut maximum

49 mm

B1A Cutting edge length Pos. A

8.52 mm

B1B Cutting edge length Pos. B

8.52 mm

B2A Insert width Pos. A

6.5 mm

B2B Insert width Pos. B

6.5 mm

B3A Inscribed circle diameter Pos. A

6.5 mm

B3B Inscribed circle diameter Pos. B

6.5 mm

BLDA Tool style code Position A

4

BLDB Tool style code Position B

4

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

5.2 mm

C1B Insert thickness Pos. B

5.2 mm

CCONMS Connection count machine side

2

CICT Cutting item count

28

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

2 - With Coolant exit, radial

D1A Corner radius Pos. A

0.4 mm

D1B Corner radius Pos. B

0.4 mm

D4A Cutting edge angle major Pos. A

90 Degree

D4B Cutting edge angle major Pos. B

90 Degree

D6A Wiper edge length Pos. A

4.8 mm

D6B Wiper edge length Pos. B

4.8 mm

DC Cutting diameter

40 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

2/2/2018

DIN

ZYL03201015

FamilyProducts

Extended Flute Endmills Carrying H490 ANKX 09... Double-Sided Rectangular Insert

HAND Cutting direction

R - Right

ID Technical product number

3105904

Interface codes

J6 / J61

ISO

ZYL10G3200h$06

ISYC Subclass

307-07 - Non-centre cutting multiple rows end mill

KAPR Tool cutting edge angle

90 Degree

LH Head length

63 mm

LOC-02 BI Block index

2

LOC-02 MIID Master insert identification

H490 ANCX 090404PDR

LOC-02-Connection-codes

J44 / J441 - Insert (Unknown 02)

LOC-02-DIN

AN0904PN3R

LOC-03 CCFMS Connection code form

10

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03 ISO

ZYL10G3200h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03201015

Name Identifying order number

H490 ANK D40-49-4-W32-09C

OAL Overall length

125 mm

TCDCONMS ISO-tolerance class shank diameter

h6

Working process

No working processes available

WT Weight of item

0.66 kg

ZEFF Face effective cutting edge count

4

ZEFP Peripheral effective cutting edge count

4
