Главная Каталог продукции Toolunited 17 307-01 - Non-centre cutting single row end mill M4D150L1504M16L175

M4D150L1504M16L175

M4D150L1504M16L175

M4D150L1504M16L175

Kennametal
Артикул: 5568066
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
APMX Depth of cut maximum
15.494 mm
BD Body diameter
36.068 mm
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
1
CICT Cutting item count
4
COMPC Company code
KH - Kennametal
DC Cutting diameter
38.1 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
8/27/2014
DIN
ZYL02900315
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
4
FamilyProducts
MILL 4-15 D1.50 Z4 INCH SCREW-ON MILL
GAMF Rake angle radial
-8 Degree
GAMP Rake angle axial
-15.3 Degree
HAND Cutting direction
1
ID Technical product number
5568066
Interface codes
J6 /
ISYC Subclass
307-01 - Non-centre cutting single row end mill
KAPR Tool cutting edge angle
90 Degree
LF Functional length
68.961 mm
LH Head length
44.45 mm
LOC-03 CCFMS Connection code form
03
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CZCMS Connection size code
0290
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02900315
LS Shank length
24.511 mm
MILTTY Mill tool type ISO
E - Disc mill - one side cutting
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
M4D150L1504M16L175
OAL Overall length
68.961 mm
RPMX Rotational speed maximum
19500 1/min
THSZMS Connection thread nominal size machine side
M16
Working process
No working processes available
ZEFF Face effective cutting edge count
4
ZEFP Peripheral effective cutting edge count
4
