Главная Каталог продукции Toolunited 17 307-13 - Die and mold end mill BLP D16-40-100-C16

BLP D16-40-100-C16

Артикул: 3106894

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

12 mm

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DCP Data chip provision

0 - Without data chip

DIN

ZYL01600115

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

Three Flute 240° Ball Nose Endmills Carrying Double-Sided Inserts

HAND Cutting direction

R - Right

ID Technical product number

3106894

Interface codes

J6 / J61

ISO

ZYL01G1600h$06

ISYC Subclass

307-13 - Die and mold end mill

LF Functional length

100 mm

LH Head length

40 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03 ISO

ZYL01G1600h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01600115

LPR Protruding length

52 mm

Name Identifying order number

BLP D16-40-100-C16

OAL Overall length

100 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available

WT Weight of item

0.12 kg

ZEFF Face effective cutting edge count
