T490 SMD1.50-1.72-4-.75-8

T490 SMD1.50-1.72-4-.75-8

T490 SMD1.50-1.72-4-.75-8

Iscar
Артикул: 3106945
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
1
CICT Cutting item count
24
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
38.1 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
7/7/2017
DHUB Hub diameter
35.56 mm
DIN
FDA07502230
FamilyProducts
Extended Flute Shell Mills Carrying T490 LNMT/HT 0804... Tangentially Clamped In
HAND Cutting direction
R - Right
ID Technical product number
3106945
Interface codes
J6 /
ISYC Subclass
308-04 - Shell milling cutter
LOC-02 BI Block index
2
LOC-02 MIID Master insert identification
T490 LNHT 0804..PNR
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
IS-LN0804PN3R
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
3 Inch with coolant
LOC-03 CZCMS Connection size code
0750
LOC-03 DCONMS Diameter
19.05 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA07502230
Name Identifying order number
T490 SMD1.50-1.72-4-.75-8
OAL Overall length
63.5 mm
Working process
No working processes available
WT Weight of item
17.018 kg
ZEFF Face effective cutting edge count
4
ZEFP Peripheral effective cutting edge count
4
