Главная Каталог продукции Toolunited 17 308-04 - Shell milling cutter T490 SM-D1.50-2-3-.75-11

T490 SM-D1.50-2-3-.75-11

T490 SM-D1.50-2-3-.75-11

T490 SM-D1.50-2-3-.75-11

Iscar
Артикул: 3107174
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
A1B Cutting edge angle major Pos. B
90 Degree
A2B Clearance angle major Pos. B
0 Degree
B1A Cutting edge length Pos. A
10.5 mm
B1B Cutting edge length Pos. B
10.5 mm
B2A Insert width Pos. A
6 mm
B2B Insert width Pos. B
6 mm
B3A Inscribed circle diameter Pos. A
6 mm
B3B Inscribed circle diameter Pos. B
6 mm
BLDA Tool style code Position A
4
BLDB Tool style code Position B
4
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
11.3 mm
C1B Insert thickness Pos. B
11.3 mm
CCONMS Connection count machine side
1
CICT Cutting item count
18
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D1A Corner radius Pos. A
0.8 mm
D1B Corner radius Pos. B
0.8 mm
D4B Cutting edge angle major Pos. B
90 Degree
D6A Wiper edge length Pos. A
0 mm
DC Cutting diameter
38.1 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
7/7/2017
DHUB Hub diameter
35.6108 mm
DIN
FDA07500230
FamilyProducts
Extended Flute Shell Mills Carrying T490 LN#T 11... Tangentially Clamped Inserts
HAND Cutting direction
R - Right
ID Technical product number
3107174
Interface codes
J6 /
ISYC Subclass
308-04 - Shell milling cutter
LOC-02 BI Block index
2
LOC-02 MIID Master insert identification
T490 LNHT 1106PNTR
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
3 Inch with coolant
LOC-03 CZCMS Connection size code
0750
LOC-03 DCONMS Diameter
19.05 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
H$07
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA07500230
Name Identifying order number
T490 SM-D1.50-2-3-.75-11
OAL Overall length
71.12 mm
TCDCONMS ISO-tolerance class shank diameter
H7
Working process
No working processes available
WT Weight of item
16.002 kg
ZEFF Face effective cutting edge count
3
ZEFP Peripheral effective cutting edge count
3
