Главная Каталог продукции Toolunited 17 308-02 - Shoulder milling cutter P290 SM D1.5-4-0.9-.75-12

P290 SM D1.5-4-0.9-.75-12

P290 SM D1.5-4-0.9-.75-12

P290 SM D1.5-4-0.9-.75-12

P290 SM D1.5-4-0.9-.75-12

Iscar

Артикул: 3110889

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

90 Degree

A2A Clearance angle major Pos. A

7 Degree

B1A Cutting edge length Pos. A

12.8 mm

B2A Insert width Pos. A

8.2 mm

B3A Inscribed circle diameter Pos. A

8.2 mm

BLDA Tool style code Position A

4

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

4.4 mm

CCONMS Connection count machine side

1

CICT Cutting item count

8

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

D1A Corner radius Pos. A

0.9 mm

D4A Cutting edge angle major Pos. A

90 Degree

D6A Wiper edge length Pos. A

1.5 mm

DC Cutting diameter

38.1 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

7/7/2017

DHUB Hub diameter

44.958 mm

DIN

FDA07500230

F23 Number of mounting layers

1

F24 Cutting item count per mounting layer

8

FamilyProducts

Extended Flute Shell Mills Carrying 12 and 18 mm Long Edged Inserts

HAND Cutting direction

R - Right

ID Technical product number

3110889

Interface codes

J6 /

ISYC Subclass

308-02 - Shoulder milling cutter

KAPR Tool cutting edge angle

90 Degree

LOC-03 CCFMS Connection code form

02

LOC-03 CCSMS Connection code style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Connection code type

FDA Milling arbor mounting

LOC-03 CCUMS Connection code unit base

3 Inch with coolant

LOC-03 CZCMS Connection size code

0750

LOC-03 DCONMS Diameter

19.05 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA07500230

Name Identifying order number

P290 SM D1.5-4-0.9-.75-12

OAL Overall length

52.9844 mm

RMPX Ramping angle maximum

0.7 Degree

Working process

No working processes available

WT Weight of item

11.684 kg

ZEFF Face effective cutting edge count

4

ZEFP Peripheral effective cutting edge count

4
