Главная Каталог продукции Toolunited 17 308-01 - Face milling cutter KSSM88D250SN3125S100Z07

KSSM88D250SN3125S100Z07

KSSM88D250SN3125S100Z07

KSSM88D250SN3125S100Z07

KSSM88D250SN3125S100Z07

Kennametal

Артикул: 5420254

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

90 Degree

A2A Clearance angle major Pos. A

0 Degree

BD Body diameter

61.4934 mm

BLDA Tool style code Position A

2

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

1

CDX Cutting depth maximum

9.1694 mm

CICT Cutting item count

7

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

63.5 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

64.135 mm

Delivery state valid from

8/27/2014

DHUB Hub diameter

55.626 mm

DIN

FDA10000220

F23 Number of mounting layers

1

F24 Cutting item count per mounting layer

7

FamilyProducts

KSSM 8+ SHELLMILL D=2.5 Z=7

GAMF Rake angle radial

-4 Degree

GAMP Rake angle axial

10 Degree

HAND Cutting direction

R - Right

ID Technical product number

5420254

Interface codes

J6 /

ISYC Subclass

308-01 - Face milling cutter

KAPR Tool cutting edge angle

88 Degree

LCCB Counterbore depth connection bore

44.45 mm

LOC-03 CCFMS Connection code form

22

LOC-03 CCSMS Connection code style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Connection code type

FDA Milling arbor mounting

LOC-03 CCUMS Connection code unit base

2 Inch

LOC-03 CZCMS Connection size code

1000

LOC-03 DCONMS Diameter

25.4 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA10000220

MILTTY Mill tool type ISO

F - T-slot end mills

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

KSSM88D250SN3125S100Z07

RPMX Rotational speed maximum

28400 1/min

Working process

FEC - Square shoulder milling,FFO - Die milling,FPL - Face milling

ZEFF Face effective cutting edge count

7

ZEFP Peripheral effective cutting edge count

7
