Главная Каталог продукции Toolunited 17 308-01 - Face milling cutter KCRA80Z08S27RN12

KCRA80Z08S27RN12

KCRA80Z08S27RN12

KCRA80Z08S27RN12

Kennametal
Артикул: 5704058
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
0 Degree
A2A Clearance angle major Pos. A
0 Degree
B3A Inscribed circle diameter Pos. A
12.7 mm
BD Body diameter
60 mm
BLDA Tool style code Position A
10
C1A Insert thickness Pos. A
4.76 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
6.4 mm
CICT Cutting item count
8
CNSC Coolant entry style code
2 - With Coolant entry, radial
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
67 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
80 mm
DIN
FDA02702210
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
8
FamilyProducts
End mill KRCA
HAND Cutting direction
R - Right
ID Technical product number
5704058
Interface codes
J6 /
ISYC Subclass
308-01 - Face milling cutter
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0270
LOC-03 DCONMS Diameter
27 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA02702210
Name Identifying order number
KCRA80Z08S27RN12
OAL Overall length
50 mm
RPMX Rotational speed maximum
17600 1/min
Working process
No working processes available
WT Weight of item
1.19 kg
ZEFF Face effective cutting edge count
8
ZEFP Peripheral effective cutting edge count
8
