Главная Каталог продукции Toolunited 17 308-01 - Face milling cutter FMR02-080-A27-RC20-04

FMR02-080-A27-RC20-04

Артикул: FMR02-080-A27-RC20-04

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

7 Degree

B3A Inscribed circle diameter Pos. A

20 mm

BLDA Tool style code Position A

C1A Insert thickness Pos. A

6.35 mm

CCONMS Connection count machine side

CDX Cutting depth maximum

10 mm

CICT Cutting item count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

ZCC - ZCC Cutting Tools

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

60 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

80 mm

Delivery state valid from

7.97 kg

DIN

FDA02702200

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

Face mill

HAND Cutting direction

R - Right

ID Identifying order number

FMR02-080-A27-RC20-04

Interface codes

J6 /

ISYC Subclass

308-01 - Face milling cutter

LOC-03 CCFMS Form

LOC-03 CCSMS Style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Type

FDA Milling arbor mounting

LOC-03 CCUMS Unit base

0 Metric

LOC-03 CZCMS Size code

0270

LOC-03 DCONMS Diameter

27 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA02702200

OAL Overall length

50 mm

Working process

FDR - Rotary milling, turn milling,FEC - Square shoulder milling,FFO - Die milling,FPL - Face milling,FPR - Profile milling,FRU - Round moulding,FSE - Counter-sinking,FZI - Circular milling

WT Weight of item

0.7 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
