Главная Каталог продукции Toolunited 17 309-00 - Tool holder for indexable inserts unspecified HSK-T100-DCMNL12+DDMNL15

HSK-T100-DCMNL12+DDMNL15

HSK-T100-DCMNL12+DDMNL15

HSK-T100-DCMNL12+DDMNL15

Ceratizit
Артикул: 11571018
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
0 Degree
BDRED Body diameter reduced
100 mm
BI Block index
1
BLDA Tool style code Position A
3
C1A Insert thickness Pos. A
4.76 mm
CEATC Tool cutting edge angle type code
S - Side lead angle
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
CE - Ceratizit
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DCC Design configuration style code
A - Solid steel, with internal coolant supply
DCP Data chip provision
0 - Without data chip
DIN
HSK10000795
EPSR Insert included angle
80 Degree
FamilyProducts
HSK-T Turning head MaxiLock D Form C ISO M 50°(C
HAND Cutting direction
L - Left
ID Technical product number
11571018
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
309-00 - Tool holder for indexable inserts unspecified
KAPR Tool cutting edge angle
50 Degree
LF Functional length
150 mm
LOC-01 BI Block index
1
LOC-01 EPSR Insert included angle
80 Degree
LOC-01 MIID Master insert identification
CN..1204../DN..1506..
LOC-01 MTP Clamping type code 1st step
M Top and hole clamping, with cylindrical hole
LOC-01-Connection-codes
J41 / J441 - Interface code position A (cutting edge) (Unknown 01)
LOC-03 CCFMS Connection code form
07
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
1000
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK10000795
LPR Protruding length
150 mm
LTA Length tool assembly
150 mm
MIID Master insert identification
CN..1204../DN..1506..
MTP Clamping type code
M - Top and hole clamping, with cylindrical bore
MTP Clamping type code 1st step
M
Name Identifying order number
HSK-T100-DCMNL12+DDMNL15
WF Functional width
0.5 mm
Working process
No working processes available
