Главная Каталог продукции Toolunited 17 309-04 - Turning tool for OD grooving and parting X4FR0752503DJET

X4FR0752503DJET

X4FR0752503DJET X4FR0752503DJET X4FR0752503DJET

X4FR0752503DJET

Seco
Артикул: 02823300
В наличии
В корзину
Описание
Характеристики
A1A SKJ Cutting edge angle major Pos. A
2
A2A SKJ Stechbreite Nennmaß Schneidkörper Pos.A
2.15 mm
BLDA SKJ Tool style code Position A
2
CDX Cutting depth maximum
6.5 mm
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CW Cutting width
3 mm
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2018
DIN
VKT12120125
DIN CSW1
SO-SO X4 2503R
FamilyProducts
X4FR0752503DJET
G1A SKJ Schneidkörperlänge Schneidkörper Pos.A
19 mm
G7A SKJ Schneidkantenhöhe Schneidkörper Pos.A
20.361 mm
HAND Cutting direction
R - Right
HF Functional height
19.05 mm
ID Technical product number
02823300
Interface codes
J6 /
Interface codes CSW1
J41 / J441
ISO CSW1
SO$$X42503**2RB
ISYC Subclass
309-04 - Turning tool for OD grooving and parting
KAPR Tool cutting edge angle
90 Degree
LF Functional length
152.4 mm
LH Head length
36.6 mm
LOC-03 B Shank width
19.05 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
VKT Square mounting
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
1212
LOC-03 H Shank height
19.05 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT12120125
MIID Master insert identification
X42503R
Name Identifying order number
X4FR0752503DJET
WF Functional width
22 mm
Working process
No working processes available
WT Weight of item
0.458 kg
