Главная Каталог продукции Toolunited 17 309-04 - Turning tool for OD grooving and parting LH100.3225.3.06

LH100.3225.3.06

LH100.3225.3.06

LH100.3225.3.06

Paul Horn
Артикул: LH1003225306
В наличии
В корзину
Описание
Характеристики
CDX Cutting depth maximum
33 mm
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
HORN - Paul Horn
CW Cutting width
6 mm
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
7/1/2015
DIN
VKT32250105
DIN CSW1
HORN-10006
FamilyProducts
Toolholder
HAND Cutting direction
L - Left
HF Functional height
40 mm
ID Technical product number
LH1003225306
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-04 - Turning tool for OD grooving and parting
LF Functional length
170 mm
LH Head length
50 mm
LOC-03 B Shank width
25 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
VKT Square mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
3225
LOC-03 H Shank height
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT32250105
LPR Protruding length
60 mm
Name Identifying order number
LH100.3225.3.06
OAL Overall length
170 mm
SX Shank cross section shape code
02 - Square shank
WF Functional width
25.2 mm
Working process
No working processes available
