Главная Каталог продукции Toolunited 17 309-08 - System tool for external threading KM40TSLSSR16

KM40TSLSSR16

Артикул: 3950857

В наличии

В корзину

Описание

Характеристики

CEDC Cutting edge count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

WI - Widia

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

Delivery state valid from

2/5/2017

DIN

KMT04000185

DIN CSW1

WI-LT16ER

FamilyProducts

tool holder for LT threading

HAND Cutting direction

R - Right

ID Technical product number

3950857

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-08 - System tool for external threading

LF Functional length

40 mm

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

KMT KM connection KENNAMETAL / UTS connection WIDIA

LOC-03 CCUMS Unit base

8 non-dimensional size

LOC-03 CZCMS Size code

0400

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KMT04000185

LPR Protruding length

40 mm

LTA Length tool assembly

40 mm

Name Identifying order number

KM40TSLSSR16

WF Functional width

27 mm

Working process

No working processes available

WT Weight of item

0.31 kg
