Главная Каталог продукции Toolunited 17 309-08 - System tool for external threading HSK63TLSSR22

HSK63TLSSR22

HSK63TLSSR22

HSK63TLSSR22

Kennametal
Артикул: 3897558
В наличии
В корзину
Описание
Характеристики
CEATC Tool cutting edge angle type code
E - Front lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KH - Kennametal
DCP Data chip provision
0 - Without data chip
Delivery state valid from
8/27/2014
DIN
HSK06300795
DIN CSW1
KH-LT22ER
FamilyProducts
HSK-T ADAPTER
GAMF Rake angle radial
-1.5 Degree
GAMP Rake angle axial
-10 Degree
HAND Cutting direction
R - Right
HF Functional height
0 mm
ID Technical product number
3897558
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-08 - System tool for external threading
KAPR Tool cutting edge angle
90 Degree
LF Functional length
70.0024 mm
LOC-03 CCFMS Connection code form
07
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0630
LOC-03 DCONMS Diameter
62.992 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300795
LPR Protruding length
70.0024 mm
LTA Length tool assembly
70.0024 mm
MIID Master insert identification
LT22ER
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
HSK63TLSSR22
OAL Overall length
101.9048 mm
WF Functional width
32.004 mm
Working process
No working processes available
