C6 PCLOL-45065-19-IQ

C6 PCLOL-45065-19-IQ

C6 PCLOL-45065-19-IQ

Iscar
Артикул: C6 PCLOL-45065-19-IQ
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
-7 Degree
B3A Inscribed circle diameter Pos. A
19.05 mm
BLDA Tool style code Position A
3
C1A Insert thickness Pos. A
6.35 mm
CEATC Tool cutting edge angle type code
S - Side lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DCP Data chip provision
0 - Without data chip
Delivery state
7/1/2017
DIN
CCS06300195
DIN CSW1
CO1906 2N
EPSR Insert included angle
80 Degree
FamilyProducts
Lever Lock and Dovetail Pocket Tool C-PCLOR/L
GAMF Rake angle radial
-6 Degree
GAMP Rake angle axial
-6 Degree
HAND Cutting direction
L - Left
HF Functional height
0 mm
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-07 - System tool for external turning
KAPR Tool cutting edge angle
95 Degree
L Cutting edge length
19 mm
LF Functional length
65 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
CCS Coromant Capto System SANDVIK
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0630
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
CCS06300195
LPR Protruding length
65 mm
LTA Length tool assembly
65 mm
MIID Master insert identification
COMG1906
Name Identifying order number
C6 PCLOL-45065-19-IQ
WF Functional width
45 mm
Working process
DDA - External turning
