Главная Каталог продукции Toolunited 17 309-01 - Tool holder for longitudinal and transversal turning DCBNL3225P16-M

DCBNL3225P16-M

DCBNL3225P16-M

Seco

Артикул: 02588103

В наличии

В корзину

Описание

Характеристики

CEDC Cutting edge count

1

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

SO - SECO Tools

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

Delivery state valid from

3/14/2020

DIN

VKT32250105

EPSR Insert included angle

80 Degree

FamilyProducts

DCBNL3225P16-M

GAMO Rake angle orthogonal

-6 Degree

HAND Cutting direction

L - Left

ID Technical product number

02588103

Interface codes

J6 /

Interface codes CSW1

/ J441

ISISO A Indicator for ISO cutting plate Pos.A

0

ISO CSW1

ISO$CN1606**2LB****

ISYC Subclass

309-01 - Tool holder for longitudinal and transversal turning

KAPR Tool cutting edge angle

75 Degree

LAMS Inclination angle

-6 Degree

LF Functional length

170 mm

LH Head length

42 mm

LOC-03 B Shank width

25 mm

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

VKT Square mounting

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

3225

LOC-03 H Shank height

32 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

VKT32250105

MIID Master insert identification

CN1606

MTP Clamping type code

D

Name Identifying order number

DCBNL3225P16-M

STDDES Standard designation

DCBNL3225P16-M

THSC Tool holder shape code

G - straight shank design

WF Functional width

22 mm

Working process

No working processes available

WT Weight of item

1.04 kg
