Главная Каталог продукции Toolunited 17 309-01 - Tool holder for longitudinal and transversal turning A32S-PVLNR13

A32S-PVLNR13

A32S-PVLNR13

Seco

Артикул: 00091720

В наличии

В корзину

Описание

Характеристики

CEDC Cutting edge count

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

SO - SECO Tools

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DCP Data chip provision

0 - Without data chip

Delivery state valid from

3/14/2020

DIN

ZYL03202215

DMIN Minimum bore diameter

40 mm

EPSR Insert included angle

35 Degree

FamilyProducts

A32S-PVLNR13

GAMO Rake angle orthogonal

-5 Degree

HAND Cutting direction

R - Right

ID Technical product number

00091720

Interface codes

J6 /

Interface codes CSW1

/ J441

ISISO A Indicator for ISO cutting plate Pos.A

0

ISO CSW1

ISO$VN1304**2RB****

ISYC Subclass

309-01 - Tool holder for longitudinal and transversal turning

KAPR Tool cutting edge angle

95 Degree

LAMS Inclination angle

-14 Degree

LF Functional length

250 mm

LH Head length

50 mm

LOC-03 B Shank width

31 mm

LOC-03 CCFMS Connection code form

22

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03 H Shank height

30 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03202215

MIID Master insert identification

VN1304

MTP Clamping type code

P - Hole clamping, with straight bore

Name Identifying order number

A32S-PVLNR13

STDDES Standard designation

A32S-PVLNR13

THSC Tool holder shape code

A - offset shank design

WF Functional width

23 mm

Working process

No working processes available

WT Weight of item

1.226 kg
