SPKN1504EDR K125M

Артикул: SPKN1504EDR K125M

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

CB Chip breaker face count

0 - Without chip breaker

CHW Corner chamfer width

1.422 mm

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

Delivery state

LH - Stocked

DIN

SP1504ED1R

EPSR Insert included angle

90 Degree

FamilyProducts

INSERT SPKN L

GRD2ND Standard designation of the grade 2nd application

HW-P20

GRD3RD Standard designation of the grade 3rd application

HW-P30

GRDMFG Grade manufacturers designation

K125M

GRDPRIO Standard designation of the grade main application

HW-P25

IC Inscribed circle diameter

15.875 mm

IFS Insert mounting style code

1 - Without bore

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

KRINS Cutting edge angle major

75 Degree

L Cutting edge length

15.875 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SP1504ED1R

Name Identifying order number

SPKN1504EDR K125M

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

SPKN1504EDR

TCINS Tolerance class insert

K - Cold formed

Working process

No working processes available
