SPHX1205PCSR-GPB CG4

Артикул: SPHX1205PCSR-GPB CG4

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

CECC Cutting edge condition code

S - Chamfered and rounded

CHW Corner chamfer width

0.7 mm

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

5 mm

Delivery state

LH - Stocked

DIN

KH-WP SPHX901205

EPSR Insert included angle

90 Degree

FamilyProducts

FIX-PERFECT INSERT MILLING 8S

GRDMFG Grade manufacturers designation

CG4

IFS Insert mounting style code

4 - Counter bore for screws with taper angle from 70° to 90°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

6.5 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

KH-WP SPHX901205

Name Identifying order number

SPHX1205PCSR-GPB CG4

RE Corner radius

0.1 mm

S Insert thickness

5.5 mm

S1 Insert thickness total

5.5 mm

STDDES Standard designation

SPHX1205PCSR

TCINS Tolerance class insert

Working process

No working processes available
