SPGX0602AP K125M

Артикул: SPGX0602AP K125M

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

BN Face land width

0.2 mm

CHW Corner chamfer width

1 mm

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

2.5 mm

Delivery state

LH - Stocked

DIN

KH-WP SPGX0602

EPSR Insert included angle

90 Degree

FamilyProducts

ISO INSERT MILLING

GB Face land angle

12 Degree

GRD2ND Standard designation of the grade 2nd application

HW-P20

GRD3RD Standard designation of the grade 3rd application

HW-P30

GRDMFG Grade manufacturers designation

K125M

GRDPRIO Standard designation of the grade main application

HW-P25

IC Inscribed circle diameter

6.35 mm

IFS Insert mounting style code

7 - Prismatic clamping, concave

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

6.35 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

KH-WP SPGX0602

Name Identifying order number

SPGX0602AP K125M

S Insert thickness

2.38 mm

S1 Insert thickness total

2.38 mm

STDDES Standard designation

SPGX0602AP

TCINS Tolerance class insert

Working process

No working processes available
