Главная Каталог продукции Toolunited 17 201-02 - Square insert SPER150416ENGB KC725M

SPER150416ENGB KC725M

Артикул: 1181459

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

Delivery state

LH - Stocked

DIN

SP1504EN1N

EPSR Insert included angle

90 Degree

FamilyProducts

INSERT SPER

GRDMFG Grade manufacturers designation

KC725M

IC Inscribed circle diameter

15.875 mm

ID Technical product number

1181459

IFS Insert mounting style code

1 - Without bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

15.875 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

SP1504EN1N

Name Identifying order number

SPER150416ENGB KC725M

RE Corner radius

1.6 mm

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

SPER150416EN

STDDESAnsi Standard designation ANSI

SPER534EN

TCINS Tolerance class insert

Working process

FEC - Square shoulder milling,FPL - Face milling,FFO - Die milling,FNU - Groove milling
