SNHX1205T KC792M

Артикул: SNHX1205T KC792M

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

BN Face land width

0.1 mm

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

5 mm

Delivery state

LH - Stocked

DIN

KH-WP SNHX10

EPSR Insert included angle

90 Degree

FamilyProducts

ISO INSERT MILLING

GRDMFG Grade manufacturers designation

KC792M

IC Inscribed circle diameter

12.7 mm

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

12.7 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

KH-WP SNHX10

Name Identifying order number

SNHX1205T KC792M

S Insert thickness

5.4 mm

S1 Insert thickness total

5.4 mm

TCINS Tolerance class insert

Working process

No working processes available
