Главная Каталог продукции Toolunited 17 302-01 - Twist Drill SCD570-1103-1-1-120HA06-HU607

SCD570-1103-1-1-120HA06-HU607

Артикул: 30658464

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

COATN Coating / Покрытие

unbeschichtet

COMPC Company code

MP - Mapal

DC Cutting diameter minimum

11.03 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

DIN

ZYL01200105

FamilyProducts

Mono-Drill-Plastic solid carbide twist drill SCD57 (5xD)

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

HU607

HAND Cutting direction

R - Right

ID Technical product number

30658464

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

71 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01200105

LS Shank length

45 mm

LU Usable length

56 mm

Name Identifying order number

SCD570-1103-1-1-120HA06-HU607

NOF Flute count

OAL Overall length

118 mm

SIG Point angle 1st step

120 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling
