Главная Каталог продукции Toolunited 17 302-01 - Twist Drill MDW1860HGS3

MDW1860HGS3

Артикул: MDW1860HGS3

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

4 - With Coolant entry, axial on hole circle

COATN Coating / Покрытие

DEX (TiAlCr/TiSi)

COMPC Company code

SU - Sumitomo

CXSC Coolant exit style code

4 - With Coolant exit, axial on hole circle

DC Cutting diameter minimum

18.6 mm

DCONMSLD Shank diameter lower limit

-0.013 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

11/15/2016

DIN

ZYL01900115

FamilyProducts

MDW..HGS Super Multi Drill 3xD

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

ACX70

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

98.9 mm

LF Functional length

164 mm

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

ZYL cylindrical shank

LOC-03 CCUMS Unit base

1 Metric with coolant

LOC-03 CZCMS Size code

0190

LOC-03 DCONMS Diameter

19 mm

LOC-03 TCDCONCDMS Tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01900115

LPR Protruding length

117.9 mm

LS Shank length

69 mm

LU Usable length

65.1 mm

Name Identifying order number

MDW1860HGS3

NOF Flute count

OAL Overall length

167.9 mm

PL Point length

3.9 mm

SIG Point angle 1st step

135 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling
