Главная Каталог продукции Toolunited 17 302-01 - Twist Drill K125A04063 K715

K125A04063 K715

Артикул: 1762649

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter minimum

10.32 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

5/5/2017

DIN

ZYL04380135

FamilyProducts

Dynapoint TF Drill – 3 Flute with Coolant, K125

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

K715

HAND Cutting direction

R - Right

ID Technical product number

1762649

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

66.04 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

3 Inch with coolant

LOC-03 CZCMS Connection size code

0438

LOC-03 DCONMS Diameter

11.1125 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL04380135

LPR Protruding length

68.58 mm

LS Shank length

64.516 mm

LU Usable length

53.1114 mm

Name Identifying order number

K125A04063 K715

NOF Flute count

OAL Overall length

133.096 mm

PL Point length

2.581 mm

SIG Point angle 1st step

130 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling
