Главная Каталог продукции Toolunited 17 302-01 - Twist Drill B323N10600 CS5

B323N10600 CS5

Артикул: B323N10600 CS5

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

COMPC Company code

KH - Kennametal

DC Cutting diameter minimum

10.6 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DIN

ZYL01100105

FamilyProducts

BF-DRILL B323N TiN CTD

GRDMFG Grade manufacturers designation

CS5

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CZCMS Connection size code

0110

LOC-03 DCONMS Diameter

11 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01100105

LPR Protruding length

33 mm

Name Identifying order number

B323N10600 CS5

OAL Overall length

95 mm

PL Point length

1.71 mm

SIG Point angle 1st step

140 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling
