Главная Каталог продукции Toolunited 17 302-01 - Twist Drill B228Z13500 CS5

B228Z13500 CS5

Артикул: B228Z13500 CS5

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

COMPC Company code

KH - Kennametal

DC Cutting diameter minimum

13.5 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

FamilyProducts

Dynapoint SE Two Flute "Drydrill" B261

GRDMFG Grade manufacturers designation

CS5

HAND Cutting direction

R - Right

Interface codes

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

51 mm

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CZCMS Connection size code

0135

LOC-03 DCONMS Diameter

13.5 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LPR Protruding length

51 mm

LU Usable length

35 mm

Name Identifying order number

B228Z13500 CS5

OAL Overall length

102 mm

PL Point length

2.1 mm

SIG Point angle 1st step

140 Degree

Working process

BVB - Drilling
