Главная Каталог продукции Toolunited 17 302-01 - Twist Drill B228Z06000 CS5

B228Z06000 CS5

Артикул: B228Z06000 CS5

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

COMPC Company code

KH - Kennametal

DC Cutting diameter minimum

6 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DIN

KH-BVSE2286

FamilyProducts

Dynapoint SE Two Flute "Drydrill" B261

GRDMFG Grade manufacturers designation

CS5

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

28 mm

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KH-BVSE2286

LPR Protruding length

28 mm

LU Usable length

21 mm

Name Identifying order number

B228Z06000 CS5

OAL Overall length

66 mm

PL Point length

1 mm

SIG Point angle 1st step

140 Degree

Working process

BVB - Drilling
