B228Z05500 CS5

Артикул: B228Z05500 CS5

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

COMPC Company code

KH - Kennametal

DC Cutting diameter minimum

5.5 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DIN

KH-BVSE2285.5

FamilyProducts

Dynapoint SE Two Flute "Drydrill" B261

GRDMFG Grade manufacturers designation

CS5

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

28 mm

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CZCMS Connection size code

0055

LOC-03 DCONMS Diameter

5.5 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KH-BVSE2285.5

LPR Protruding length

28 mm

LU Usable length

21 mm

Name Identifying order number

B228Z05500 CS5

OAL Overall length

66 mm

PL Point length

0.9 mm

SIG Point angle 1st step

140 Degree

Working process

BVB - Drilling
