Главная Каталог продукции Toolunited 17 302-01 - Twist Drill B201A08800 CD2

B201A08800 CD2

Артикул: B201A08800 CD2

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

8.8 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DIN

ZYL01000105

FamilyProducts

Dynapoint SE Two Flute "Drydrill" B261

GRDMFG Grade manufacturers designation

CD2

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

40 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0100

LOC-03 DCONMS Diameter

10 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01000105

LPR Protruding length

45 mm

LS Shank length

40 mm

LU Usable length

29 mm

Name Identifying order number

B201A08800 CD2

OAL Overall length

85 mm

PL Point length

1.4 mm

SIG Point angle 1st step

140 Degree

Working process

BVB - Drilling
