Главная Каталог продукции Toolunited 17 302-01 - Twist Drill B125A14000 K715

B125A14000 K715

Артикул: 1762705

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter minimum

14 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

5/5/2017

DIN

ZYL01400115

FamilyProducts

TF-Bohrer mit Innenkühlung

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

K715

HAND Cutting direction

R - Right

ID Technical product number

1762705

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

77 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0140

LOC-03 DCONMS Diameter

14 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01400115

LPR Protruding length

79 mm

LS Shank length

76 mm

LU Usable length

60 mm

Name Identifying order number

B125A14000 K715

NOF Flute count

OAL Overall length

155 mm

PL Point length

3.5 mm

SIG Point angle 1st step

130 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling
