Главная Каталог продукции Toolunited 17 302-01 - Twist Drill B102Z15000 KMF

B102Z15000 KMF

Артикул: B102Z15000 KMF

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

COMPC Company code

KH - Kennametal

DC Cutting diameter minimum

15 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DIN

KH-BVTF10215

FamilyProducts

TF-DRILL B102Z

GRDMFG Grade manufacturers designation

KMF

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-01 - Twist Drill

LCF Length chip flute

38 mm

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CZCMS Connection size code

0150

LOC-03 DCONMS Diameter

15 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KH-BVTF10215

LPR Protruding length

56 mm

Name Identifying order number

B102Z15000 KMF

OAL Overall length

115 mm

PL Point length

2.7 mm

SIG Point angle 1st step

130 Degree

Working process

BVB - Drilling
