DGM50CTB UE6020

Артикул: DGM50CTB UE6020

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

12 Degree

ANL Clearance angle flank left hand

6 Degree

ANR Clearance angle flank right hand

6 Degree

CB Chip breaker face count

0 - Without chip breaker

COMPC Company code

MI - Mitsubishi Materials

CRE Spot radius

2.5 mm

CW Cutting width

5 mm

CWLD Cutting width lower deviation

0.05 mm

CWUD Cutting width upper deviation

-0.05 mm

Delivery state valid from

4/1/2022

DIN

MI-DG50

FamilyProducts

insert type DGM...CTB (M class)

GRD2ND Standard designation of the grade 2nd application

HC-P30

GRDMFG Grade manufacturers designation

UE6020

GRDPRIO Standard designation of the grade main application

HC-P20

IFS Insert mounting style code

1 - Without bore

IH Insert hand

N - Neutral

INSL Insert length

25 mm

Interface codes

J6 /

ISYC Subclass

202-06 - Insert, two cutting edges for profiling

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

MI-DG50

Materials

P,K

Name Identifying order number

DGM50CTB UE6020

NOF Flute count

NT Tooth count

PFS Profile form

TPT Thread profile type

V - Full profile

Working process

No working processes available
