Главная Каталог продукции Toolunited 16 202-04 - Insert, two cutting edges for parting, self clamping GX09-1S0.90L SR127

GX09-1S0.90L SR127

Артикул: GX09-1S0.90L SR127

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

6 Degree

ANL Clearance angle flank left hand

1 Degree

ANR Clearance angle flank right hand

1 Degree

CB Chip breaker face count

1 - With chip breaker one-side

COMPC Company code

CE - Ceratizit

CW Cutting width

0.9 mm

CWLD Cutting width lower deviation

0.02 mm

CWUD Cutting width upper deviation

0.02 mm

D1 Fixing hole diameter

0 mm

FamilyProducts

carbide parting and grooving insert

GRD2ND Standard designation of the grade 2nd application

HC-K20

GRD3RD Standard designation of the grade 3rd application

HC-M20

GRDMFG Grade manufacturers designation

SR127

GRDPRIO Standard designation of the grade main application

HC-P25

IFS Insert mounting style code

7 - Prismatic clamping, concave

IH Insert hand

L - Left

INSL Insert length

9 mm

Interface codes

ISYC Subclass

202-04 - Insert, two cutting edges for parting, self clamping

KCHTR Flank chamfer angle right hand

45 Degree

Materials

P,M,K,S,H

Name Identifying order number

GX09-1S0.90L SR127

NOF Flute count

PDPT Profile depth insert

1.04 mm

PFS Profile form

PSIRL Cutting edge angle major left hand

0 Degree

PSIRR Cutting edge angle major right hand

0 Degree

W1 Insert width

1.4 mm

Working process

No working processes available
