Главная Каталог продукции Toolunited 16 202-02 - Insert, one cutting edge for grooving and parting, self clamping 12356723185

12356723185

Артикул: 12356723185

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

COATN Coating

Plasma-CVD

COMPC Company code

WI - Widia

CW Cutting width

3 mm

CWLD Cutting width lower deviation

0.05 mm

CWUD Cutting width upper deviation

0.15 mm

Delivery state valid from

8.5 €

DIN

WI-123567231

FamilyProducts

ProGroove insert

GRD2ND Standard designation of the grade 2nd application

HC-M30

GRDMFG Grade manufacturers designation

TPC35

GRDPRIO Standard designation of the grade main application

HC-P35

ID Technical product number

12356723185

IH Insert hand

L - Left

Interface codes

J6 /

ISYC Subclass

202-02 - Insert, one cutting edge for grooving and parting, self clamping

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

WI-123567231

Name Identifying order number

12356723185

NOF Flute count

PFS Profile form

PSIRL Cutting edge angle major left hand

6 Degree

PSIRR Cutting edge angle major right hand

0 Degree

REL Corner radius left hand

0 mm

RER Corner radius right hand

0.25 mm

Working process

No working processes available
