Главная Каталог продукции Toolunited 16 202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth 22IR5,0ISO LCM25T

22IR5,0ISO LCM25T

Артикул: 22IR5,0ISO LCM25T

В наличии

В корзину

Описание

Характеристики

COMPC Company code

BK - Boehlerit

Delivery state valid from

1/10/2016

DIN

BK-GS22IR

FamilyProducts

Indexable Insert - Internal Thread, ISO-Metric

GRD2ND Standard designation of the grade 2nd application

HC-K20

GRDMFG Grade manufacturers designation

LCM25T

GRDPRIO Standard designation of the grade main application

HC-M20

IC Inscribed circle diameter

15.88 mm

IH Insert hand

R - Right

INSL Insert length

27 mm

Interface codes

J6 /

ISYC Subclass

202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

BK-GS22IR

Name Identifying order number

22IR5,0ISO LCM25T

NOF Flute count

NT Tooth count

PDX Profile distance X

2.3 mm

PDY Profile distance Y

1.6 mm

PFS Profile form

S1 Insert thickness total

4.6 mm

STDDES Standard designation

22IR5,0ISO

THFT Thread form type

TPN Thread pitch minimum

5 mm

TPT Thread profile type

V - Full profile

TPX Thread pitch maximum

5 mm

TTP Thread type

I - Internal thread

Working process

DGI - Thread turning, internal
