Главная Каталог продукции Toolunited 16 202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth 22ERN60 LCM25T

22ERN60 LCM25T

Артикул: 22ERN60 LCM25T

В наличии

В корзину

Описание

Характеристики

COMPC Company code

BK - Boehlerit

Delivery state valid from

1/10/2016

DIN

BK-GS22ER

FamilyProducts

Indexable Insert - External Thread, Profile 60°

GRD2ND Standard designation of the grade 2nd application

HC-K20

GRDMFG Grade manufacturers designation

LCM25T

GRDPRIO Standard designation of the grade main application

HC-M20

IC Inscribed circle diameter

12.7 mm

IH Insert hand

R - Right

INSL Insert length

22 mm

Interface codes

J6 /

ISYC Subclass

202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

BK-GS22ER

Name Identifying order number

22ERN60 LCM25T

NOF Flute count

NT Tooth count

PDX Profile distance X

2.5 mm

PDY Profile distance Y

1.7 mm

PFS Profile form

RETL Flank radius left hand

0.51 mm

RETR Flank radius right hand

0.51 mm

S1 Insert thickness total

4.6 mm

STDDES Standard designation

22ERN60

THFT Thread form type

60°

TPIN Threads per inch minimum

TPIX Threads per inch maximum

TPN Thread pitch minimum

3.5 mm

TPT Thread profile type

T - Partial profile

TPX Thread pitch maximum

5 mm

TTP Thread type

A - External thread

Working process

DGA - Thread turning, external
