Главная Каталог продукции Toolunited 16 202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth 22ER 3 SAGE IC908

22ER 3 SAGE IC908

Артикул: 5902424

В наличии

В корзину

Описание

Характеристики

CB Chip breaker face count

0 - Without chip breaker

COMPC Company code

IS - Iscar

Delivery state valid from

12/1/2014

DIN

IS-22ER

FamilyProducts

22ER 3 SAGE IC908, External thread din 513 profile

GRDMFG Grade manufacturers designation

IC908

IC Inscribed circle diameter

12.7 mm

ID Technical product number

5902424

IH Insert hand

R - Right

INSL Insert length

22 mm

Interface codes

J6 /

ISYC Subclass

202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

IS-22ER

Name Identifying order number

22ER 3 SAGE IC908

NOF Flute count

NT Tooth count

PDPT Profile depth insert

1.5 mm

PFS Profile form

STDDES Standard designation

22ER 3 SAGE

THFT Thread form type

SAGE

TPN Thread pitch minimum

2.4 mm

TTP Thread type

A - External thread

Working process

DGA - Thread turning, external
