Главная Каталог продукции Toolunited 16 202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth 16IL8NPTF LCM25T

16IL8NPTF LCM25T

Артикул: 16IL8NPTF LCM25T

В наличии

В корзину

Описание

Характеристики

COMPC Company code

BK - Boehlerit

Delivery state valid from

1/10/2016

DIN

BK-GS16IL

FamilyProducts

Indexable Insert - Internal Thread, NPTF

GRD2ND Standard designation of the grade 2nd application

HC-K20

GRDMFG Grade manufacturers designation

LCM25T

GRDPRIO Standard designation of the grade main application

HC-M20

IC Inscribed circle diameter

9.52 mm

IH Insert hand

L - Left

INSL Insert length

16 mm

Interface codes

J6 /

ISYC Subclass

202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

BK-GS16IL

Name Identifying order number

16IL8NPTF LCM25T

NOF Flute count

NT Tooth count

PDX Profile distance X

1.8 mm

PDY Profile distance Y

1.3 mm

PFS Profile form

S1 Insert thickness total

3.4 mm

STDDES Standard designation

16IL8NPTF

THFT Thread form type

NPTF

TPIN Threads per inch minimum

TPT Thread profile type

V - Full profile

TTP Thread type

I - Internal thread

Working process

DGI - Thread turning, internal
